100LW Laser Welding/Cutting/Cleaning helmet

Superior laser protection with adjustable shade number

Key features

Effective laser protection01

Designed to meet EN207 OD10+@1064nm, the 100LW provides full protection to prevent eye burns, retinal damage and other tissue damage.

Advanced Headgear design02

Viewing angle and distance adjustable. Offers a better weight distribution for maximum comfortable feelings.

Ultra-clear vision03

Experience exceptional clarity and details with TECMEN's light state 2.0 variable shade laser lens. Superior vision quality leads to superior work quality.

Smart adjustment04

Shade number, delay and sensitivity all easily adjustable using our user-friendly panel.

Specifications

More information about our products

Specifications

ADF Model

100LW

Viewing Area

96x46.5mm

Optical Class

1 / 1 / 1 / 2

Number of Sensors

Power On/Off

Automatic On/Off

Dark State

4-8/8-12

Light State

Shade 2.0

Switching Speed

1/25,000s, from Light to Dark

Special Modes

GRIND / CUT / MIX / DARK

Sensitivity Control

Low-High,button control

Delay

0.1-1.0s,button control

UV/IR Protection

Up to Shade DIN 16 at all times

Operating Temp

-10℃ to 55℃（14℉ to 131℉）

Storing Temp

-20℃ to 70℃（-4℉ to 158℉）

Helmet Material

special compound material

Laser Protection

1000-1100 D LB7+ IR LB8

Optical Density(OD)

OD 8@1000-1100nm, OD 10+@1064nm

Approvals

CE（EN 207, EN ISO 16321）
